All New Voltex LED batten - No more fluro tube replacements, a 7 year warranty, and substantial energy savings.
- Weatherproof (IP66) Vandal Resistant fittings
- Polycarbonate lens and base - UV stabilised (Material: V-0 Rating)
- High output LG® LED chips
- OSRAM® LED driver (Non Dimmable)
- All fixings and brackets supplied
- Stainless Steel clips
- Ideal for outdoors and washdown bays
- 7 year warranty
- Lumens: 2500Lm
- Operating Temp: -20˚C to +40˚C
- Dimensions: 600mm (L) x 120mm (W) x 108mm (H)
Product Code | LW624-5K |
Input Voltage | 200-260 VAC 50/60Hz |
Opal diffuser material | UV Stabilized Polycarbonate (PC) Opaque White |
Body material | Polycarbonate (PC) Grey |
Fireproof grade | V-0 |
Input Power (Watts) | 24W |
Clips & Mounting Brackets | 304 Stainless Steel |
Terminal Block | 3 Poles Screw Terminal 6mm² capacity |
Driver Efficiency | >85.1 |
Driver | OSRAM® OPTOTRONIC (Non Dimmable) |
LED Brand | LG® |
LED Type | SMD2835 |
LED Qty (Pcs) | 50 |
CCT - Colour Temperature (Kelvin) | 5000K |
CRI (Colour Rendering Index) | >80 |
Typical Lumens (+/-5%) | 2500Lm |
Lighting Efficiency | up to 105Lm/W |
Power Factor | >0.95 |
Beam Angle | 120° |
IK rating (Input Resistance) | IK08 (Protection against 5 joule impact) |
IP rating | IP66 |
Warranty | 7 years |
Certificates | ROHS, EN62471, ISO 9001:2008 |
Net Weight | 1.3kg |
Product Size (mm) | 600 (L) x 120 (W) x 108 (H) |
Fixing Hole Centre | 330mm |
Maximum Luminaires per circuit (Typical) Type C 16A |
85 |
Operating temperature | -20°C to +40°C |
