Introducing the new CUBO switchboard range from Voltex.
Developed to suit the specific requirements of the Australian electrical contractor. These IP40 flush mount boards range from 12 to 36 way and are suitable for both solid and hollow wall installation.
![Time is Money](https://www.voltexelectrical.com.au/skins/skin_3/images2/landing_page/cubo-switchboard-range/section_2_img_1.png)
Time is Money
We know your time is valuable, which is why we have completely pre-assembled each board.
The result is a quicker installation, with less plastic packaging to dispose of so you can work more efficiently.
No more using your noggin
The new clamping system gives you the flexibility in positioning the board, eliminating the need to secure to a stud or nogging. No measuring needed. Simply trace around the board, cut, and then fasten the brackets to the back of the plasterboard.
But don't worry, if you prefer to install before sheeting you can still use our stud mounting accessory
![](https://www.voltexelectrical.com.au/skins/skin_3/images2/landing_page/cubo-switchboard-range/section_3_img_1.jpg)
![](https://www.voltexelectrical.com.au/skins/skin_3/images2/landing_page/cubo-switchboard-range/section_3_img_2.jpg)
Convenience
The Earth and Neutral Bars have been customised based on your feedback. The entry terminals take 35mm2 cable, and the bars offer double screw connection. The screws are captive and wound out from production to save you time. Each bar is configurable to suit a variety of situations.
![](https://www.voltexelectrical.com.au/skins/skin_3/images2/landing_page/cubo-switchboard-range/section_4_img_1.png?v=1)
![](https://www.voltexelectrical.com.au/skins/skin_3/images2/landing_page/cubo-switchboard-range/25_year_warranty_logo.png)
If you prefer to install before sheeting, use our stud mounting accessory
General
Room temperature range | -25 ºC / +40 ºC |
Maximum operating voltagea | 1000VAC / 1500VDC |
Colour and Material (Front Panel and Door) |
ABS White RAL 9003. UV Stabilized. |
Colour and Material (Base) |
PS (V0) Grey RAL 7035. |
Accessories included |
Pole fillers, module identification label, spare clamping bracket, and circuit labelling set. |
Protection Plate | Depending on the installation location, this board may need to be protected to comply as WSX3 mechanical protection system (Section H 5.4 from AS3000). If so, you can order the relevant plate here. |
Enclosure
Compliance | AS 62208-2006 |
Degree of Protection | IP40 |
Resistance to impact | IK08 |
Auto-extinguishing degree | V-0 (AS/NZS 60695-11-10) |
Compliance | AS/NZS 60998.2.1:2012 |
Rated current | 125A |
Supply terminals | 7.8mm (accepts 35mm2 cable) |
Other terminals | 5.2mm (accepts 16mm2 cable) |
Screw details | PH2/Flat screwheads. Clear passivated steel. Rounded ends. Captive in bar. Wound out from production. |
